| 机组型号 Model | 功率Power | 电 流 A Current | 发动机型号 Engine model | 缸 数 Cylinder | 缸径*行程 Bore*Stroke D | 排 气 量 L isplacemen | 机油容量L t Lube oil | 油耗g/kw .h Consumption | 尺寸mm Size | 重量Kg Weight | |
| KW | KVA | ||||||||||
| 重庆康明斯(国二)系列 | |||||||||||
| YDK-200GF | 200 | 250 | 360 | NT855-GA | 6 | 140*152 | 14 | 38 | 191 | 3000*1050*1800 | 2550 |
| YDK-250GF | 250 | 312.5 | 450 | NTA855-G1A | 6 | 140*152 | 14 | 38 | 193 | 3100*1050*1800 | 2600 |
| YDK-280GF | 280 | 350 | 504 | NTA855-G1B | 6 | 140*152 | 14 | 38 | 209 | 3100*1050*1800 | 2700 |
| YDK-300GF | 300 | 375 | 540 | NTA855-G2A | 6 | 140*152 | 14 | 38 | 191 | 3100*1050*1800 | 2800 |
| YDK-320GF | 320 | 400 | 576 | NTA855-G4 | 6 | 140*152 | 14 | 38 | 197 | 3100*1100*1900 | 2900 |
| YDK-320GF | 320 | 400 | 576 | NTAA855-G7 | 6 | 140*152 | 14 | 38 | 207 | 3300*1100*1900 | 3000 |
| YDK-350GF | 350 | 437.5 | 630 | NTAA855-G7A | 6 | 140*152 | 14 | 38 | 200 | 3350*1100*1900 | 3100 |
| YDK-400GF | 400 | 500 | 720 | QSNT-G4X | 6 | 140*152 | 14 | 39 | 211 | 3400*1200*1900 | 3200 |
| YDK-400GF | 400 | 500 | 720 | KTA19-G3 | 6 | 159*159 | 19 | 50 | 205 | 3500*1380*2000 | 3800 |
| YDK-450GF | 450 | 562.5 | 810 | KTA19-G3A | 6 | 159*159 | 19 | 50 | 202 | 3500*1380*2000 | 3900 |
| YDK-450GF | 450 | 562.5 | 810 | KTA19-G4 | 6 | 159*159 | 19 | 50 | 202 | 3500*1380*2000 | 3900 |
| YDK-480GF | 480 | 600 | 864 | KTAA19-G6 | 6 | 159*159 | 19 | 50 | 216 | 3600*1550*2200 | 4300 |
| YDK-500GF | 500 | 625 | 900 | KTA19-G8 | 6 | 159*159 | 19 | 50 | 204 | 3500*1400*2100 | 4200 |
| YDK-500GF | 500 | 625 | 900 | KTAA19-G6A | 6 | 159*159 | 19 | 50 | 216 | 3600*1550*2200 | 4500 |
| YDK-600GF | 600 | 750 | 1080 | KT38-GA | 12 | 159*159 | 38 | 135 | 221 | 4300*1800*2500 | 7100 |
| YDK-640GF | 640 | 800 | 1152 | KTA38-G2 | 12 | 159*159 | 38 | 135 | 206 | 4350*1800*2500 | 7300 |
| YDK-700GF | 700 | 875 | 1260 | KTA38-G2B | 12 | 159*159 | 38 | 135 | 198 | 4350*1800*2500 | 7600 |
| YDK-800GF | 800 | 1000 | 1440 | KTA38-G2A | 12 | 159*159 | 38 | 135 | 203 | 4400*1800*2500 | 7800 |
| YDK-824GF | 824 | 1030 | 1483.2 | KTA38-G5 | 12 | 159*159 | 38 | 135 | 200 | 4450*1800*2500 | 7900 |
| YDK-900GF | 900 | 1125 | 1620 | KTA38-G9 | 12 | 159*159 | 38 | 135 | 193 | 4450*1800*2500 | 8200 |
| YDK-1000GF | 1000 | 1250 | 1800 | KTA50-G3 | 16 | 159*159 | 50 | 177 | 202 | 5100*2100*2600 | 9600 |
| YDK-1000GF | 1000 | 1250 | 1800 | KTA50-G12 | 16 | 159*159 | 50 | 177 | 194 | 5350*2100*2600 | 9600 |
| YDK-1200GF | 1200 | 1500 | 2160 | KTA50-G8 | 16 | 159*159 | 50 | 204 | 205 | 5400*2150*2600 | 9800 |
| YDK-1200GF | 1200 | 1500 | 2160 | KTA50-GS8 | 16 | 159*159 | 50 | 204 | 205 | 5600*2150*2600 | 10800 |
| YDK-1320GF | 1320 | 1650 | 2376 | KTA50-G15X | 16 | 159*159 | 50 | 204 | 204 | 5600*2200*2800 | 11000 |
| YDK-1600GF | 1600 | 2000 | 2880 | KTA50-G16B | 16 | 159*159 | 50 | 204 | 191 | 5700*2200*2800 | 12000 |
| 机组型号 Model | 功率Power | 电 流 A Current | 发动机型号 Engine model | 缸 数 Cylinder | 缸径*行程 Bore*Stroke D | 排 气 量 L isplacemen | 机油容量L t Lube oil | 油耗g/kw .h Consumption | 尺寸mm Size | 重量Kg Weight | |
| KW | KVA | ||||||||||
| 重庆康明斯(国三)系列 | |||||||||||
| YDK-220GF | 220 | 275 | 396 | QSM11-G1 | 6 | 125*147 | 10.8 | 37 | 223 | 3000*1150*1800 | 2900 |
| YDK-250GF | 250 | 312.5 | 450 | QSM11-G2 | 6 | 125*147 | 10.8 | 37 | 216 | 3000*1150*1800 | 3000 |
| YDK-280GF | 280 | 350 | 504 | QSM11-G3 | 6 | 125*147 | 10.8 | 37 | 206 | 3000*1150*1800 | 3100 |
| YDK-300GF | 300 | 375 | 540 | QSM11-G5 | 6 | 125*147 | 10.8 | 37 | 205 | 3100*1150*1800 | 3200 |
| YDK-320GF | 320 | 400 | 576 | QSM11-G6 | 6 | 125*147 | 10.8 | 37 | 205 | 3100*1150*1800 | 3200 |
| YDK-350GF | 350 | 437.5 | 630 | QSNT-G3 | 6 | 140*152 | 14 | 39 | 205 | 3200*1200*1800 | 3300 |
| YDK-400GF | 400 | 500 | 720 | QSK19-G14 | 6 | 159*159 | 19 | 83 | 207 | 3500*1400*2100 | 4500 |
| YDK-450GF | 450 | 562.5 | 810 | KTA19-G8E | 6 | 159*159 | 19 | 50 | 206 | 3600*1420*2100 | 4400 |
| YDK-500GF | 500 | 625 | 900 | KTA19-G8A | 6 | 159*159 | 19 | 50 | 205 | 3700*1420*2100 | 4500 |
| YDK-500GF | 500 | 625 | 900 | QSK19-G4 | 6 | 159*159 | 19 | 84 | 216 | 3650*1570*2200 | 4700 |
| YDK-550GF | 550 | 687.5 | 990 | KTA19-G9A | 6 | 159*159 | 19 | 50 | 205 | 3700*1450*2100 | 4700 |
| YDK-550GF | 550 | 687.5 | 990 | QSK19-G19 | 6 | 159*159 | 19 | 84 | 197 | 3800*1950*2300 | 4800 |
| YDK-600GF | 600 | 750 | 1080 | QSK19-G20 | 6 | 159*159 | 19 | 84 | 194 | 3800*1950*2300 | 5100 |
| YDK-640GF | 640 | 800 | 1152 | QSK19-G21 | 6 | 159*159 | 19 | 84 | 198 | 3850*1950*2300 | 5200 |
| YDK-720GF | 720 | 900 | 1296 | KTA38-G5E | 12 | 159*159 | 38 | 135 | 205 | 4800*2150*2550 | 7500 |
| YDK-720GF | 720 | 900 | 1296 | QSK38-G9 | 12 | 159*159 | 38 | 144 | 220 | 4600*2050*2550 | 7600 |
| YDK-800GF | 800 | 1000 | 1440 | QSK38-G10 | 12 | 159*159 | 38 | 144 | 214 | 4600*2050*2550 | 7800 |
| YDK-850GF | 850 | 1062.5 | 1530 | KTA38-G7E | 12 | 159*159 | 38 | 135 | 203 | 4800*2150*2550 | 8000 |
| YDK-900GF | 900 | 1125 | 1620 | KTA38-G9E | 12 | 159*159 | 38 | 135 | 203 | 4800*2150*2550 | 8200 |
| YDK-900GF | 900 | 1125 | 1620 | QSK38-G11 | 12 | 159*159 | 38 | 144 | 206 | 4600*2050*2550 | 8300 |
| YDK-1000GF | 1000 | 1250 | 1800 | KTA38-G9A | 12 | 159*159 | 38 | 173 | 197 | 4900*2150*2550 | 8500 |
| YDK-1000GF | 1000 | 1250 | 1800 | KTA50-G3E | 16 | 159*159 | 50 | 177 | 204 | 5500*2150*2600 | 9800 |
| YDK1000GF | 1000 | 1250 | 1800 | QSK38-G5 | 12 | 159*159 | 38 | 144 | 199 | 4870*2150*2500 | 9200 |
| YDK1000GF | 1000 | 1250 | 1800 | QSK38-G12 | 12 | 159*159 | 38 | 144 | 199 | 4800*2100*2550 | 9200 |
| YDK-1100GF | 1100 | 1375 | 1980 | KTA50-G7E | 16 | 159*159 | 50 | 177 | 203 | 5500*2150*2600 | 9900 |
| YDK-1100GF | 1100 | 1375 | 1980 | QSK38-G13 | 12 | 159*159 | 38 | 144 | 193 | 4800*2100*2550 | 9300 |
| The parameters above is about:rotating speed 1500RPM,frequency 50HZ,rated voltage 400/230V,power factor 0.8,three phase four line of wiring mode.60HZ diesel generator sets can be customized.The generator can use Wuxi Stamford,Shanghai Marathon,Shanghai Hengsheng and other well-known brands according to customer needs.This parameter table is for reference if have change no notice in the future. | |||||||||||
